预计 2025 年晶片贴装设备市场规模为 15.4 亿美元，到 2030 年将达到 20.7 亿美元，预测期内（2025-2030 年）的复合年增长率为 6.09%。

晶片贴装设备-市场-IMG1

物联网 (IoT) 设备中堆迭晶粒技术的日益广泛使用推动了成长。最近的趋势表明，由于医疗、军事、光电和无线电子等新兴和成熟的应用，对混合电路的需求仍然强劲。

关键亮点

  • C2W 混合键合是一种很有前景的新技术，可实现直接 Cu-Cu 键合，并可取代 TCB 用于 3D 堆迭记忆体和高阶逻辑应用。然而，C2W 混合键结仍处于起步阶段。预计该技术将于2022-2023年在2.5D逻辑装置市场推出，大幅推动设备市场的成长。
  • 对 AuSn 共晶晶片黏接技术的需求将推动市场发展。传统上，晶片采用各种各样的晶片粘接产品进行粘接，包括金属填充的导电环氧树脂、高铅焊料和金硅焊料，以确保它们在设备的整个使用寿命内可靠地运行。
  • 然而，发热量不断增加的趋势、设备小型化的需求、RoHS和REACH的建立以及向GaAs晶片的过渡限制了传统材料的使用。对高设备可靠性的需求促使工程师评估各种用于晶粒黏合的新材料。
  • 提案的焊料预製件是共晶金锡，可用于大规模生产或在实验室中使用 Palomar Technologies 晶片焊接机。该设备能够完成完整的晶片黏接过程，包括高精度拾取和放置基板、共晶金锡预製件和组件、共晶晶片黏接和使用电脑控制脉衝热台（PHS）进行脉衝热回流焊接。
  • 对分立功率元件的需求正在推动市场的发展。作为传统电线和带状接头的替代品，铜夹正变得越来越受欢迎。晶片黏接特性是分立功率元件封装解决方案的特性。宽能带隙半导体晶粒技术（SiC 和 GaN）的采用带来了新的创新封装解决方案，包括银烧结晶片黏接（材料包括环氧模塑料和互连材料）。
  • EV/HEV 应用中从分立 SiC 到 SiC 模组的逐步过渡、嵌入式晶粒封装系统以及多晶片系统中 GaN 装置的整合只是这些趋势的几个例子。这导致对分立功率元件晶片贴装设备的需求增加。
  • 然而，加工过程中的尺寸变化、使用寿命以及设备加工过程中运动部件的机械不平衡等因素可能会对设备功能构成挑战并限制市场的发展。

晶片贴装设备市场趋势

LED 越来越受欢迎

  • 晶片黏接材料是中功率、高功率和高功率LED 性能和可靠性的关键。随着LED渗透率的不断提高，对晶片贴装设备的需求也日益增加。为特定的晶片结构和应用选择合适的晶片黏合材料取决于许多考虑因素，包括封装製程（产量和产量比率）、性能（散热和光输出）、可靠性（流明维持率）和成本。共晶金锡、载银环氧树脂、焊料、硅胶和烧结材料均已用于 LED 晶片黏合。
  • 例如，SFE提供一种环氧胶粘合方法，其LED环氧固晶机的索引时间为0.2秒/週期（90％的运行率），晶片尺寸为250*250标准，并描述了透过两个相机进行导线架识别。此软体功能包括自动安装水平和拾取水平教学功能。
  • 此外，导电黏合剂（主要是含银环氧树脂）是 LED 最广泛使用的热晶片黏接材料（以单位数计算）。它们与现有的后处理封装设备相容，并提供具有吸引力的性价比（通常高达 50W/mK 的热性能以及二次回流焊接相容性）。由于它附着在裸硅上，因此它是没有后端金属化的晶粒的首选材料，例如硅上的 GaN。
  • 此外，儘管LED市场上有许多对手和竞争者，但ASM是该市场上最突出的参与企业之一，其LED环氧树脂高速晶片焊接机AD830在LED市场占据主导地位。随着越来越多的国家希望逐步淘汰传统灯泡，LED 继续占据市场主导地位。根据联合研究中心的数据，LED 营收渗透率正在上升，预计到 2025 年将达到 75.8%。这推动了晶片贴装设备市场的需求。
  • 此外，2022 年 9 月，Palomar Technologies 宣布推出其新型晶片贴片机 3880-II，该产品荣获 2022 年军事+航空航天电子创新奖。新机器包括可最大限度提高生产率、减少高达 95% 的编程时间并提高整体黏合机生产率的选项。

亚太地区占据显着的市场成长

  • 亚太地区在晶片贴装设备产业中占有显着的成长。全球超过 60% 的外包半导体组装和测试（OSAT）公司总部设在亚太地区。这些 OSAT 公司在其半导体製造过程中使用晶片贴装设备。此外，该地区的IDM（集成设备製造商）数量正在增加，预计这将很快推动市场成长。
  • 在中国和台湾，包括光电子、MEMS和MOEMS在内的多种设备被用于智慧型手机、穿戴式装置和白色家电家用电子电器等电子产品的大量生产。所有这些设备在组件组装过程中都需要晶片贴装设备。
  • 此外，预计预测期内韩国、中国以及日本的人口老化将加速对医疗保健服务的需求，为包含 MEMS 压力感测器的人工呼吸器、透析和血压监测设备等提供发展空间。亚太经社会预测，到2025年，该地区60岁及以上人口数量将从目前的9.55人增加到10.64人，到2050年将增加到18.44人，占世界人口的60%。 MEMS压力感测器晶片贴装设备的需求正在促进该市场的成长。
  • 此外，由于政府的倡议，印度正在发展许多智慧城市，并有望采用电子解决方案来实现监控、维护和监视等目的。根据smartcities.gov.in报道，中央政府已拨款9.77亿美元用于建造60个这样的智慧城市。这导致对更多CMOS影像感测器的需求，从而进一步推动市场成长。
  • 高功率雷射在切割、焊接和加工等多种应用领域中得到广泛需求。该公司正在转向雷射技术以利用其高性能和可靠性。雷射二极体的进步极大地增加了对处理环氧树脂和共晶键合技术的设备的需求。
  • 物联网、人工智慧和 ADAS 的发展预计将进一步增加记忆体需求。因此，现在比以前更需要提高储存晶片製造的生产率和后处理设备的可靠性。为了解决这个问题，2022 年 8 月，史丹佛大学的工程师宣布，他们将创建更有效率、更灵活的 AI 晶片，有可能将 AI 的力量带入微型边缘设备，有助于提高记忆体製造的吞吐量和可靠性。

晶片贴装设备产业概况

由于本地和全球参与企业的存在，晶片贴装设备市场竞争激烈，因此市场呈现细分化。此外，各公司都致力于透过开发和合作来提高产量和产量比率等设备性能，加剧了市场竞争。主要参与企业包括 Be Semiconductor Industries NV、ASM Pacific Technology Limited 和 Palomar Technologies Inc.

  • 2022 年 10 月，Hermetic Solutions Group (HSG) 从 RHP Technologies 收购了 DiaCool 的智慧财产权。这扩大了 HSG 的产品线，并将在未来许多年为客户提供更多选择。 HSG 用于散热器、晶片片和散热器的 DiaCool 钻石复合材料为客户提供了比传统层压板和 MMC 材料更显着的优势。
  • 2022年10月，Kulicke和Soffa赢得了多个热压解决方案的新订单，并成功向主要客户交付了其第一台助焊剂热压键合机（TCB），继续保持其在先进LED组装领域的地位。

其他福利

  • Excel 格式的市场预测 (ME) 表
  • 3 个月的分析师支持

目录
